Connectors

ProductsConnectorsCard Socket Series

Card Socket Series

5000-6P-1.5T

  • USIM Card Socket Connector

Specification

Type USIM Socket
Rated current 1.0A / Pin (6Pin)
Rated Voltage 30V AC/DC
(size : H x W x L) 1.5 x 17.8 x 17.8

5000-8P-1.5ML3

  • Micro SIM Card Socket Connector

Specification

Type Micro SIM Socket
Rated current 1.0A / Pin (8Pin)
Rated Voltage 30V AC/DC
(size : H x W x L) 1.5 x 13.4 x 14.15

5000-FA0100

  • Nano SIM Card Socket Connector

Specification

Type Nano SIM Socket
Rated current 0.5A / Pin (6Pin)
Rated Voltage 10V AC/DC
(size : H x W x L) 1.05 x 9.7 x 12.2

HD08-AL0335

  • Micro SD Memory Card Socket Connector

Specification

Type Micro SD Memory
Rated current 0.5A / Pin (8Pin)
Rated Voltage 5V DC
(size : H x W x L) 3.35 x 11.5 x 5.5

5000-FC0600

  • Nano SIM Card & Micro SD Memory Card Socket

Specification

Type Nano SIM+Micro SD
Rated current 0.5A / Pin (17Pin)
Rated Voltage 10V AC
(size : H x W x L) 2.05 x 12.2 x 17.9

HD17-AL0245

  • Micro SIM Card & Micro SD Memory Card Socket

Specification

Type Micro SD + Micro SIM
Rated current 0.5A / Pin (17Pin)
Rated Voltage 30V AC
(size : H x W x L) 2.50 x 17.75 x 14.30
