Card Socket Series
5000-6P-1.5T
- USIM卡Socket连接器
Specification
Type | USIM Socket |
---|---|
Rated current | 1.0A / Pin (6Pin) |
Rated Voltage | 30V AC/DC |
(size : H x W x L) | 1.5 x 17.8 x 17.8 |
5000-8P-1.5ML3
- Micro SIM卡Socket连接器
Specification
Type | Micro SIM Socket |
---|---|
Rated current | 1.0A / Pin (8Pin) |
Rated Voltage | 30V AC/DC |
(size : H x W x L) | 1.5 x 13.4 x 14.15 |
5000-FA0100
- Nano SIM卡Socket连接器
Specification
Type | Nano SIM Socket |
---|---|
Rated current | 0.5A / Pin (6Pin) |
Rated Voltage | 10V AC/DC |
(size : H x W x L) | 1.05 x 9.7 x 12.2 |
HD08-AL0335
- Micro SD Memory卡Socket连接器
Specification
Type | Micro SD Memory |
---|---|
Rated current | 0.5A / Pin (8Pin) |
Rated Voltage | 5V DC |
(size : H x W x L) | 3.35 x 11.5 x 5.5 |
5000-FC0600
- Nano SIM卡及Micro SD Memory卡Socket
Specification
Type | Nano SIM+Micro SD |
---|---|
Rated current | 0.5A / Pin (17Pin) |
Rated Voltage | 10V AC |
(size : H x W x L) | 2.05 x 12.2 x 17.9 |
HD17-AL0245
- Micro SIM卡及Micro SD Memory卡Socket
Specification
Type | Micro SD + Micro SIM |
---|---|
Rated current | 0.5A / Pin (17Pin) |
Rated Voltage | 30V AC |
(size : H x W x L) | 2.50 x 17.75 x 14.30 |
